QC for Bird to UHF Female adapter
Nickel Plated Brass Body
Silver Plated Beryllium Copper Center Pin
Detailed Product Information
This QC for Bird to UHF Female adapter is one of several thousand RF products available from Max-Gain Systems, Inc. This adapter is a between series coaxial adapter.
This adapter is made from a Solid Brass body that is precision machined and plated with Nickel for superior performance and value. This QC for Bird to UHF Female adapter has a PTFE dielectric and a silver plated beryllium copper center pin. Our Line Section adapters allow you to interface with BNC, Type C, HN, LC, mini-UHF, Type N or SMA connectors. The QC for the Bird connection type uses four screws to secure them to the line section in order to maintain a tight connection. The UHF female side (also known as a SO-239 connection) is by far the most popular connection type used in Amateur Radio.
See our entire line RF Connectors and Adapters:
