500 MHz Low-Pass Filters (locking), General Radio Part #: 874-F500L

$35.00

500 MHz Low-Pass Filters (locking)

3 in stock

Recommended for use in immittance- or voltage-measuring systems to reduce harmonics, and especially in systems that contain nonlinear elements or sections that might resonate at a harmonic. Also useful in slotted-line measurements. Uses Chebyshev-type filters that produce a very steep cutoff characteristic at the expense of passband flatness. Spurious responses in the stopband are very small. 50 OHM impedance, locking GR-874 connector. Sourced from military surplus lots.

General Radio Part #: 874-F500L

Additional information

Shipping Weight 8.30 oz
Shipping Dimensions 10.19 × 1.01 × 1.01 in
Manufacturer

General Radio

Cut-Off Frequency

500 MHz

Connection Type

Connection Type 2

GR874

Impedance

50 OHM

Condition

Used, Surplus

itemCondition
